Features of AMD Ryzen 5 7600 7th Generation Processor ( 5.1 GHz / 6 Cores / 12 Threads )
AMD Ryzen 5 7600 is part of the Ryzen 5 lineup, using the Zen 4 (Raphael) architecture with Socket AM5. Thanks to AMD Simultaneous Multithreading (SMT) the core-count is effectively doubled, to 12 threads. Ryzen 5 7600 has 32 MB of L3 cache and operates at 3.8 GHz by default, but can boost up to 5.1 GHz, depending on the workload.
AMD is building the Ryzen 5 7600 on a 5 nm production process using 6,570 million transistors. The silicon die of the chip is not fabricated at AMD, but at the foundry of TSMC. You may freely adjust the unlocked multiplier on Ryzen 5 7600, which simplifies overclocking greatly, as you can easily dial in any overclocking frequency.
With a TDP of 65 W, the Ryzen 5 7600 consumes typical power levels for a modern PC. AMD's processor supports DDR5 memory with a dual-channel interface. The highest officially supported memory speed is 5200 MT/s, but with overclocking (and the right memory modules) you can go even higher. ECC memory is supported, too, which is an important capability for mission-critical systems, to avoid data corruption. For communication with other components in the system, Ryzen 5 7600 uses a PCI-Express Gen 5 connection. This processor features the Radeon Graphics integrated graphics solution.
Hardware virtualization is available on the Ryzen 5 7600, which greatly improves virtual machine performance. Programs using Advanced Vector Extensions (AVX) will run on this processor, boosting performance for calculation-heavy applications. Besides AVX, AMD has added support for the newer AVX2 and AVX-512 instructions, too.
Specifications of AMD Ryzen 5 7600 7th Generation Processor ( 5.1 GHz / 6 Cores / 12 Threads )
| Model |
RYZEN-5-7600 |
| Product Code |
100-100001015BOX |
| Platform |
Desktop |
| Product Family |
AMD Ryzen™ Processors |
| Market Segment |
Enthusiast Desktop |
| Product Line |
AMD Ryzen™ 5 Processors |
| AMD PRO Technologies |
No |
| Consumer Use |
Yes |
| Regional Availability |
Global |
| Former Codename |
“Raphael AM5” |
| Architecture |
“Zen 4” |
| Multithreading (SMT) |
Yes |
| # of CPU Cores |
6 |
| # of Threads |
12 |
| Max. Boost Clock |
Up to 5.1GHz |
| Base Clock |
3.8GHz |
| L1 Cache |
384KB |
| L2 Cache |
6MB |
| L3 Cache |
32MB |
| Default TDP |
65W |
| Processor Technology for CPU Cores |
TSMC 5nm FinFET |
| Processor Technology for I/O Die |
TSMC 6nm FinFET |
| CPU Compute Die (CCD) Size |
71mm² |
| I/O Die (IOD) Size |
122mm² |
| Package Die Count |
2 |
| Unlocked for Overclocking |
Yes |
| AMD EXPO™ Memory Overclocking Technology |
Yes |
| Precision Boost Overdrive |
Yes |
| Curve Optimizer Voltage Offsets |
Yes |
| AMD Ryzen™ Master Support |
Yes |
| CPU Socket |
AM5 |
| Supporting Chipsets |
X670E
X670
B650E
B650 |
| CPU Boost Technology |
Precision Boost 2 |
| Instruction Set |
x86-64
|
| Supported Extensions |
AES, AMD-V, AVX, AVX2, AVX512, FMA3, MMX( ), SHA, SSE, SSE2, SSE3, SSE4.1, SSE4.2, SSE4A, SSSE3, x86-64 |
| Thermal Solution (PIB) |
AMD Wraith Stealth |
| Max. Operating Temperature (Tjmax) |
95°C |
| *OS Support |
Windows 11 – 64-Bit Edition
Windows 10 – 64-Bit Edition
RHEL x86 64-Bit
Ubuntu x86 64-Bit
*Operating System (OS) support will vary by manufacturer. |
| Connectivity |
|
| USB Type-C® Support |
Yes |
| Native USB 3.2 Gen 2 (10Gbps) Ports |
4 |
| Native USB 3.2 Gen 1 (5Gbps) Ports |
0 |
| Native USB 2.0 (480Mbps) Ports |
1 |
| Native SATA Ports |
0 |
| PCI Express® Version |
PCIe® 5.0 |
| Native PCIe® Lanes (Total/Usable) |
28/24 |
| Additional Usable PCIe Lanes from Motherboard |
AMD X670E 12x Gen4
AMD X670 12x Gen4
AMD B650E 8x Gen4
AMD B650 8x Gen4 |
| NVMe Support |
Boot, RAID0, RAID1, RAID10 |
| System Memory Type |
DDR5 |
| Memory Channels |
2 |
| Max. Memory |
128GB |
| System Memory Subtype |
UDIMM |
| Max Memory Speed |
2x1R DDR5-5200
2x2R DDR5-5200
4x1R DDR5-3600
4x2R DDR5-3600 |
| ECC Support |
Yes (Requires mobo support) |
| Graphics Capabilities |
|
| Integrated Graphics |
Yes |
| Graphics Model |
AMD Radeon™ Graphics |
| Graphics Core Count |
2 |
| Graphics Frequency |
2200 MHz |
| GPU Base |
400 MHz |
| USB Type-C® DisplayPort™ Alternate Mode |
Yes |
| Key Features |
|
| Supported Technologies |
AMD EXPO™ Technology
AMD Ryzen™ Technologies |
| Warranty |
3 Years |
| Note |
*** Features, Price, Specifications are subject to change without notice. |
