Description
Features of TPLink TL-WR941HP 450Mbps High Power Wireless N Router
- Superior Range – High power amplifiers and high-gain antennas provide enhanced wireless range.
- Wall-Penetrating Wi-Fi – Enhanced Wi-Fi signal cuts through walls and obstacles, eliminating dead zones
- 3 Modes Functionality – Offers three wireless modes, including Router, Range Extender, and Access Point
- 450Mbps Wireless Speed – Ideal for video streaming, online gaming and VoIP
Specifications of TPLink TL-WR941HP 450Mbps High Power Wireless N Router
| WIRELESS | |
| Standards |
Wi-Fi 4 IEEE 802.11n/b/g 2.4 GHz |
| WiFi Speeds |
N450 2.4 GHz: 450 Mbps (802.11n) |
| WiFi Range |
4 Bedroom Houses3× Detachable 9 dBi High-Gain Antennas Multiple antennas form a signal-boosting array to cover more directions and large areas High-Power FEM |
| WiFi Capacity | Legacy |
| Working Modes |
Router Mode Access Point Mode Range Extender Mode |
| HARDWARE | |
| Processor | Single-Core CPU |
| Ethernet Ports |
1× 10/100 Mbps WAN Port 4× 10/100 Mbps LAN Ports |
| Buttons |
Wi-Fi On/Off Button Power On/Off Button WPS Button Reset Button |
| Power | 12 V ⎓ 1.5 A |
| SECURITY | |
| WiFi Encryption |
WEP WPA WPA2 WPA/WPA2-Enterprise (802.1x) |
| Network Security |
SPI Firewall Access Control IP & MAC Binding Application Layer Gateway |
| Guest Network | 1× 2.4 GHz Guest Network |
| VPN Server |
OpenVPN PPTP |
| SOFTWARE | |
| Protocols |
IPv4 IPv6 |
| Parental Controls |
URL Filtering Time Controls |
| WAN Types |
Dynamic IP Static IP PPPoE PPTP L2TP |
| Quality of Service | QoS by Device |
| NAT Forwarding |
Virtual Server Port Forwarding Port Triggering DMZ UPnP |
| IPTV |
IGMP Proxy IGMP Snooping |
| DHCP |
Address Reservation DHCP Client List Server |
| DDNS |
NO-IP DynDNS |
| Management | Tether App |
| OTHER | |
| System Requirements |
Internet Explorer 11+, Firefox 12.0+, Chrome 20.0+, Safari 4.0+, or other JavaScript-enabled browser
Cable or DSL Modem (if needed) Subscription with an internet service provider (for internet access) |
| Certifications | FCC, CE, RoHS |
| Environment |
Operating Temperature: 0℃~40℃ (32℉ ~104℉) Storage Temperature: -40℃~70℃ (-40℉ ~158℉) Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~90% non-condensing |
| TEST DATA | |
| WiFi Transmission Power |
CE: <20dBm(2.4GHz) FCC: <30dBm |
| WiFi Reception Sensitivity |
450M: -71dBm@10% PER 130M: -74dBm@10% PER 108M: -74dBm@10% PER 54M: -77dBm@10% PER 11M: -91dBm@8% PER 6M: -89dBm@10% PER 1M: -97dBm@8% PER |
| PHYSICAL | |
| Dimensions (W×D×H) |
9.0 × 7.5 × 1.9 in (227.5 × 190 × 48.3mm) |
| Package Contents |
Wi-Fi Router TL-WR941HP Power Adapter RJ45 Ethernet Cable Quick Installation Guide |
