Description
Features of THERMALTAKE The View 390 Air Future Dusk ATX Mid Tower Cabinet ( Black )
The Thermaltake View 390 Air Mid Tower Chassis is a spacious, high-performance ATX case with a unique 4mm one-piece curved tempered glass side and top panel for a stunning full internal view. It features a perforated front panel for optimised airflow and supports up to eleven 120mm fans, dual 200mm front fans, and 360mm radiators. Designed for modern builds, it accommodates CPU coolers up to 160mm, GPUs up to 420mm, and offers versatile cable management and GPU support.
Hidden-Connector MotherboardsDesigned for next-gen builds, the View 390 Air Mid Tower Chassis supports both standard and hidden-connector motherboards from ASUS, MSI, and GIGABYTE.
*Compatible with hidden-connector motherboards:
ASUS BTF Series
MSI PROJECT ZERO Series
GIGABYTE PROJECT STEALTH Series
Performance You Can See
The View 390 Air Mid Tower Chassis features a 4mm curved tempered glass side panel for a distinctive look.
Air Intake and Exhaust
Thanks to the perforated front panel and two CT120 rear fans, the View 390 Air Mid Tower Chassis still has well-designed cold air intakes and hot air exhausts to keep the internal temperature low at all times.
Two CT120 PC Cooling Fans Pre-installed
The View 390 Air Mid Tower Chassis features two 120mm PWM fans at the rear to provide efficient cooling performance.
Space for many cooling options
The View 390 Air Mid Tower can support up to two 200mm fans at the front, up to eleven 120mm fans in total, and a 360mm AIO radiator at the front or the motherboard side, providing excellent cooling capability.
Horizontal or Vertical GPU Mounting
The rotatable PCI-E slots support both horizontal and vertical GPU mounting. An included GPU holder and riser cable bracket also help to support the GPU and prevent sagging.
Storage Support
The drive plate at the right chamber of the chassis supports up to two 3.5" HDDs or up to three 2.5" SSDs for storage expansion.
Everything within Reach
Two USB 3.0, one USB 3.2 Gen 2 Type C, one reset button and HD Audio ports are placed on the top panel to grant direct access when needed.
Specification of THERMALTAKE The View 390 Air Future Dusk ATX Mid Tower Cabinet ( Black )
| Case Edition |
Thermaltake View 390 Air (CA-11F-00MNWN-00 ) |
| Case Form Factor | Mid Tower |
| Motherboard Form Factor | ATX MicroATX Mini-ITX |
| Back Connect Compatible | Yes |
| I/O, Bays & Expansion | |
| Front/Side/Top Panel I/O | 1 x HD Audio 2 x USB 3.0 1 x USB 3.2 Gen2 Type-C |
| Drive Bays | 1 x 2.5" Internal 2 x 3.5" / 2x 2.5" Internal |
| Standard Expansion Slots | 7 (Rotatable) |
| Vertical Expansion Slots | |
| Fans & Filters | |
| Fan Bays | 8 x 120mm 3 x 120mm / 2x 140mm / 2x 200mm |
| Fans Included | 2 x 120mm |
| Fan Controller/Hub | |
| Dust Filters | Bottom Front Side |
| Liquid Cooling Support | |
| Front Radiator Compatibility | 1 x 120/140/240/280/360mm |
| Top Radiator Compatibility | |
| Bottom Radiator Compatibility | |
| Rear Radiator Compatibility | |
| Side Radiator Compatibility | 1 x 120/240/360mm |
| Clearances | |
| Max CPU Cooler Height | 160 mm |
| Max GPU Card Length | 420 (w/out Radiator) / 390 (w/ Radiator) mm |
| Cable Routing Space | |
| Side Panels | |
| Window/s | Yes |
| Window Configuration | 1 x Main Side 1 x Top |
| Window Construction | Tempered Glass |
| LED Lighting Functionality | |
| LED Lighting | No |
| LED Lighting Emitters | |
| LED Lighting Colour | |
| LED Lighting Support & Control | |
| Power Supply Compatibility | |
| PSU Included | No |
| PSU Wattage (If Included) | |
| PSU 80+ Rating (If Included) | |
| PSU Support | ATX |
| PSU Mounting Location | Top Mount, Rear |
| Max PSU Length | 260 (w/out SSD) / 200 (w/ SSD) mm |
| Chassis Physical Specifications | |
| Colour | Purple |
| Chassis Construction Materials | SPCC / Tempered Glass |
| Front Panel Type | N/A |
| Dimensions | 287 x 503 x 485 (WxHxD mm) |
| Weight | 10.95 kg (Approx) |
| Package Type | Retail |
| Please Note | |
| Additional Information | |
| Scan Code | LN165385 |
| Model Number | CA-11F-00MNWN-00 |
| GTIN | 4711658544391 |
