Description
Features of SILVERSTONE PI01 (SST-PI01B)
The dimensions of SilverStone PI01 (SST-PI01B) are 90 mm (W) x 28 mm (H) x 62 mm (D). The heat sink is of aluminum material making it more durable. The dimensions of SilverStone PI01 (SST-PI01B)’s heatsink is 9 mm (W) x 15.2 mm (H) x 9 mm (D) and another one is 14 mm (W) x 15.2 mm (H) x 14 mm (D). The operating temperature of the thermal pad is -40 °C ~ 200 °C.
- Wall mount capable
- Aluminum casing designed for additional heat dissipation
- Two heatsinks and thermal pads included
- Compatible with Raspberry Pi 3B+/3B/2B/1B+ version
Specification of SILVERSTONE PI01 (SST-PI01B)
| Model No. | SST-PI01B |
| Color | Black |
| Material | Aluminum |
| Support Raspberry Pi Version | Raspberry Pi 3B+/3B/2B/1B+ version |
| Net weight | 55 g |
| Dimension | 90 mm (W) x 28 mm (H) x 62 mm (D) |
| Heatsink | |
| Material | Aluminum |
| Net Weight and dimension |
Heatsink 1 : 9 mm (W) x 15.2 mm (H) x 9 mm (D), 2.6 g Heatsink 2 : 14 mm (W) x 15.2 mm (H) x 14 mm (D), 6.5 g |
| Thermal Pad | |
| Thermal conductivity | 1.5W/m.k |
| Operating temperature | -40 °C ~ 200 °C |
| Thermal pad thickness | 0.5 / 1.25mm |
| Net Weight and dimension |
Blue Pad : 14 mm (W) x 0.5 mm (H) x 14 mm (D), 0.25 g Gray Pad 1: 14 mm (W) x 1.25 mm (H) x 14 mm (D), 0.4 g Gray Pad 2: 9 mm (W) x 1.25 mm (H) x 9 mm (D), 0.2 g |
