Features of LIAN LI Uni Fan SL120 V2 Reverse Blade Cabinet Fan Black
LIAN LI Uni Fan SL120 V2 Reverse Blade Cabinet Fan Black reverse blade features an interlocking system to connect up to 6 fans in two clusters to a single controller port, making fans installation and cable management a simple job.
- Reversed blade that can act as an intake fan with the front view
- Ability of daisy chain design to connect 2 clusters of fans.
- Removable interlocking keys to provide better radiator clearance.
- Start/stop fan RPM support for a quieter environment.
- Smooth side lighting for with stylish aesthetic.
CONSISTENT APPEARANCE
View the fan front way no matter intake or exhaust way.
UPGRADED MODULARITY
UNI FAN SL V2 reverse blade features an interlocking system to connect up to 6 fans in two clusters to a single controller port, making fans installation and cable management a simple job.
PLUG-IN POWER CABLE MODULE
Flush with fan frame, reduces clearance issues.
SLIDE-IN MECHANISM
Pin-to-pad contact, daisy-chaining the fan into a simple cluster.
REMOVABLE KEY
Remove the interlocking key to improve compatibility.
SINGLE CABLE TO CONTROLLER
(INCLUDED IN 3 PACK UNI FAN SL120-V2)
Combines fan power and LED signal into one cable, reduces cable clutter.
EXTENSION CABLE
(INCLUDED IN 3 PACK UNI FAN SL120-V2)
Bridges 2 fan clusters for a minimalistic cable solution.
UNCOMPROMISED PERFORMANCE
The UNI FAN SLV2 reverse blade operates with a slightly higher noise level with a better airflow compared to the original UNI FAN SLV2.
SOPHISTICATED LIGHTING DESIGN
DETAIL ORIENTED
The cut edge of the rubber pads is designed to create a smoother curve along the light diffuser.
CONTINUOUS LED CHANNEL
The light gap between the two fans when interlocked together has been reduced from 5.6mm to 3mm, sketching out the elegant lighting effects.
L-CONNECT 3 SOFTWARE TO CONTROL UNI FAN SL V2 REVERSE BLADE FANS
Control and preview with precision the lighting effect of the UNI FAN SL V2 reverse blade fans with the new L-Connect interface.
Specifications of LIAN LI Uni Fan SL120 V2 Reverse Blade Cabinet Fan Black
| Product Name | UNI FAN SL120 V2 REVERSE BLADE |
| Model | G99-12RSLV21B-IN |
| Color | Black |
| Number of Fans | 1 |
| Controller | No |
| Connection Type | 1 × 4-PIN PWM + 3-PIN ARGB |
| Material | PBT/PC/Aluminum |
| Fan Dimension | 120 X 120 X 28 (mm) |
| Rated Voltage | DC 12V (FAN) & 5V (LED) |
| Fan Speed | 0, 250~2000 RPM |
| Max Air Pressure | 2.59 mmH2O (Maximum) |
| Max Airflow | 64.5 CFM (Maximum) |
| Accoustic Noise | 32 dB(A) Max |
| Locked Current | 0 (Automatic Protection) |
| Bearing Type | Fluid Dynamic Bearing (FDB) |
| Operated Voltage | DC12V & 5V |
| Start-Up Voltage | ≦5 V |
| Input Power | 0.17A |
| Input Power | 2.04W |
| Warranty | 2 Years |
| Note** | **Prices, Specifications & Features are subject to change without notice |
