DEEPCOOL Spartacus 360mm CPU Liquid Cooler ( Black )

Features of DEEPCOOL Spartacus 360mm CPU Liquid Cooler ( Black )

• Radiator Dimensions: 402×120×27 mm(L×W×H)
• Radiator Material: Aluminum
• Tube length: 410 mm
• Pump Dimensions: 99×91×65 mm(L×W×H)
• Pump Speed: 2500~3400 RPM±10%
• Pump Connector: 4-pin PWM
• Pump Rated Voltage: 12 VDC
• Pump Rated Current: 0.29 A
• Pump Power Consumption: 3.48 W
• Fan Dimensions: 120×120×25 mm(L×W×H)
• Fan Speed: 500~2500 RPM±10% 0 RPM (PWM duty < 5%)
• Fan Airflow: 79.89 CFM
• Fan Air Pressure: 3.30 mmAq
• Fan Noise: ≤32.23 dB(A)
• Fan Connector: 4-pin PWM
• Bearing Type: Hydro Bearing
• Fan Rated Voltage: 12 VDC
• Fan Rated Current: 0.24 A
• Fan Power Consumption: 2.88W
• LED Type: Addressable RGB LED
• LED Connector: 3-pin(+5V-D-G)
• LED Rated Voltage: 5 VDC
• LED Power Consumption: 2.0 W（PUMP）
• Display Specifications: 3.4 inch 480×480 TFT LCD

SPARTACUS 360 is DeepCool’s latest generation of liquid coolers featuring an advanced customizable LCD screen. Personalize your build with modular layouts and dynamic visuals on the 3.4" IPS screen. Equipped with an upgraded Gen 6 pump and high-performance fans, it ensures exceptional cooling efficiency and quiet operation

A FORM THAT SPEAKS

With a precision-crafted design and refined metal finish, SPARTACUS 360 reflects DeepCool's commitment to modern aesthetics and build quality. The pump cap attaches magnetically for easy removal, and precision pogo pin contacts ensure a stable and reliable connection.

VIVIDLY FLUID 3.4" LCD

A 3.4" IPS display opens a new screen experience, featuring 480×480 resolution and support for 16.7 million colors. Content is structured in modular blocks, enabling a flexible visual layout tailored to individual preferences.

AI-TUNED CHILL. POWERED BY DeepCreative

With the upgraded DeepCreative interface, one click replaces BIOS tinkering — DeepCreative’s proprietary AI-driven algorithm tracks CPU load in real time and coordinates both fan and pump speeds to match the optimal fan speed curve. This ensures perfect harmony between powerful cooling and whisper-quiet operation, all without lifting a finger.

DeepCreative: THE CONTROL CENTER

Unlock a deeply visual experience with the SPARTACUS cooler through DeepCreative software. Monitor real-time system stats, customize your display with flexible block layouts, and switch between multiple modes as needed. When performance takes priority, Zen Mode reduces update frequency to minimize system load while keeping critical data visible.

DRIVEN BY THE GEN 6 PUMP

The 6th-generation pump features a 3-phase, 6-slot, 4-pole motor with FOC control, delivering smoother and more efficient operation across a PWM-adjustable range of 2,500 to 3,400 RPM. The expanded copper base and fine-tuned microfin geometry help maximize thermal transfer, enabling up to 320W of heat dissipation with low noise and long-term reliability.

STABILITY IN EVERY SPIN

SPARTACUS 360 is equipped with three high-performance 120mm fans featuring an enclosed blade-ring design that maintains structural integrity at high speeds, ensuring stable airflow and low noise. Durable hydraulic bearings provide long-term reliability, and the hidden connector layout keeps cables neatly out of sight.

SINGLE CONNECTION, TOTAL CONTROL

The unique 10-pin connector integrates power and signal for both pump and screen, eliminating cable clutter with a single, streamlined connection. Control is centralized through a compact hub, allowing independent adjustment of fan speeds and ARGB lighting per channel, with magnetic and screw mounting options for flexible installation.

PRECISION COOLING ALIGNMENT

SPARTACUS 360 features a newly engineered offset bracket optimized for Intel 24- or 20-core LGA1851 CPUs (such as the Core Ultra 9 285K or Core Ultra 7 265K). By offsetting the cold plate upward, it aligns precisely with the CPU’s hotspot and reduces temperatures by 1-3°C*.
Other Intel and AMD platforms remain fully supported with standard mounting hardware.

REAR-LOCK MOUNTING

The rear-mounted locking system allows front-side installation without screws, streamlining the process and resulting in a cleaner build.

ANTI-LEAK TECHNOLOGY

The SPARTACUS liquid coolers feature DeepCool's patented Anti-Leak Technology. The internal valve regulates pressure and purges it when internal pressure exceeds atmospheric pressure, extending the cooler's lifespan and reducing the risk of leaks.

Specification of DEEPCOOL Spartacus 360mm CPU Liquid Cooler ( Black )
