Zoom
Description
Features of ASUS TUF Gaming Radeon RX 7600 XT OC Edition 16GB
ASUS TUF Gaming Radeon™ RX 7600 XT OC Edition 16GB GDDR6 graphic card optimized inside and out for lower temps and durability.
- Axial-tech fan design: A smaller fan hub facilitates longer blades and a barrier ring that increases downward air pressure
- Dual ball fan bearings last up to twice as long as conventional designs
- Military-grade capacitors rated for 20K hours at 105C make the GPU power rail more durable
- Metal exoskeleton adds structural rigidity and vents to increase heat dissipation
- Auto-Extreme precision automated manufacturing for higher reliability
- GPU Tweak III software provides intuitive performance tweaking, thermal controls, and system monitoring.
FLYIN’ TUF
The AMD RDNA™ 3 Architecture elevated by buffed cooling and power delivery to effortlessly churn out frames at 4K resolution and beyond, and backed with an arsenal of rugged reinforcements to cover your six.
Lock, load, and dominate with the TUF Gaming Radeon™ RX 7600 XT.
AXIAL-TECH UPGRADES
Air Superiority
Three tried-and-true Axial-tech fans feature a smaller hub that facilitates longer blades and a barrier ring to increase downward air pressure
NEW DIRECTION
Well-maintained Formation
The two side fans spin counterclockwise to minimize turbulence and maximize air dispersion through the heatsink. All three fans come to a standstill when GPU temps are below 55 Celsius, letting you play less-demanding games or perform light tasks in relative silence. Fans start up again when temps are over 60 Celsius, referencing a speed curve that balances performance and acoustics for work or play.
2.96-SLOT DESIGN
Phase That Blaze
A generously sized heatsink efficiently soaks up heat from the AMD Radeon™ RX 7600 XT GPU, allowing it to be whisked away by the three Axial-tech fans.
MILITARY-GRADE 20K CAPACITORS
Resilient Squadron
A lineup of capacitors rated to last 20,000 hours at 105 Celsius brings higher temperature and ripple tolerance to the GPU power rail, arming the card for long-term deployment in challenging conditions.
METAL EXOSKELETON
Suit Up
An aluminum shroud and backplate prevent PCB flex and feature large vents to further increase heat dissipation.
LOCK, LOAD, AND LET THE PERFORMANCE FLOW
The Radeon™ RX 7600 XT gloriously presented on a backdrop of low noise and rugged durability.
AUTO-EXTREME TECHNOLOGY
RELIABILITY BOOST
Auto-Extreme Technology is an automated manufacturing process that sets new standards in the industry by allowing all soldering to be completed in a single pass. This reduces thermal strain on components and avoids the use of harsh cleaning chemicals, resulting in less environmental impact, lower manufacturing power consumption, and a more reliable product overall.
AURA SYNC
Light ‘em Up!
Aura-compatible ARGB lighting on the shroud adds a dash of customizable color or functional effects to your build. Pair up with a vast range of compatible system components and coordinate the glow to create a theme that’s uniquely you.
GRAPHICS CARD HOLDER
Pillar of Support
The bundled graphics card holder banishes sag and also contains a screwdriver to help you build.
GPU Tweak III
Monitor, tweak, and tune
ASUS GPU Tweak III is more intuitive and feature-rich than ever before. A revamped interface offers greater accessibility by integrating core functions into a centralized dashboard, and our Voltage-Frequency tuner has been overhauled to make overclocking even easier. Additional goodies like 0dB fan technology, automatic profile swapping, a fully customizable on-screen display, and logging capabilities ensure that you get the most out of your graphics card.
AMD Software
Change the way you game
The latest AMD Software unleashes the full potential of your GPU with day-0 drivers optimized for new game releases and a highly customizable gaming experience.
Specifications of ASUS TUF Gaming Radeon RX 7600 XT OC Edition 16GB
| Model | TUF-RX7600XT-O16G-GAMING |
| Part No | 90YV0K20-M0AA00 |
| Graphics Engine | AMD Radeon™ RX 7600 XT |
| Bus Standard | PCI Express 4.0 |
| OpenGL | OpenGL®4.6 |
| Video Memory | 16GB GDDR6 |
| Engine Clock | OC mode : up to 2830 MHz (Boost Clock)/up to 2559 MHz (Game Clock) Default mode : up to 2810 MHz (Boost Clock)/up to 2539 MHz (Game Clock) |
| Stream Processors | 2048 |
| Memory Clock | 18Gbps |
| Memory Interface | 128-bit |
| Resolution | Digital Max Resolution: 7680×4320 |
| Interface | Yes x 1 (Native HDMI 2.1) Yes x 3 (Native DisplayPort 2.1) HDCP Support Yes (2.3) |
| NVlink/ Crossfire Support | No |
| Multi-view | 4 |
| Recommended PSU | 600W |
| Power Connector | 2 x 8-pin |
| Accessories | 1 x TUF certificate of Reliability 1 x TUF Gaming Graphics Card Holder 1 x TUF Velcro Hook & Loop 1 x Collection card 1 x Thank you card 1 x Speedsetup Manual |
| Dimensions | 300.2 x 142.75 x 59.2 mm 11.81 x 5.6 x 2.33 inch |
| Slot | 2.96 Slot |
| AURA SYNC | ARGB |
