Features of AMD Ryzen 9 9950X3D 9 Generation Processors ( 5.7GHz / 16Core / 32 Threads )
AMD Ryzen 9 9950X3D Gaming and Content Creation Processor
The AMD Ryzen 9 9950X3D is a powerful gaming desktop processor from the Ryzen 9000 series, featuring the advanced Zen 5 architecture. With 16 CPU cores and 32 threads, it delivers excellent performance for both gaming and multitasking. The processor’s base clock operates at 4.3 GHz, providing solid performance for everyday tasks and gaming, while the maximum boost clock of up to 5.7 GHz ensures smooth gameplay and high responsiveness during more demanding applications.
Equipped with a generous 144MB total cache, the AMD Ryzen 9 9950X3D ensures faster data access, which contributes to lower latency and improved overall system efficiency. The processor has a Thermal Design Power (TDP) of 170 W, making it energy-efficient while still delivering high performance. This combination of power and efficiency makes it ideal for users who need a balance of performance and energy savings, especially in gaming systems.
The AMD Ryzen 9 9950X3D supports the AM5 socket, offering compatibility with a wide range of motherboards. It is designed to work with chipset families such as A620 , X670E , X670 , B650E , B650 , X870E , X870 , B840 & B850, providing users with a variety of options for building or upgrading their systems. It comes with AMD Radeon Graphics.
Specifications of AMD Ryzen 9 9950X3D 9 Generation Processors ( 5.7GHz / 16Core / 32 Threads )
| Name | AMD Ryzen™ 9 9950X3D |
| Family | Ryzen |
| Series | Ryzen 9000 Series |
| Form Factor | Desktops , Boxed Processor |
| Product Code | 100-100000719WOF |
| AMD PRO Technologies | No |
| Regional Availability | Global |
| Former Codename | Granite Ridge AM5 |
| Architecture | Zen 5 |
| # of CPU Cores | 16 |
| Multithreading (SMT) | Yes |
| # of Threads | 32 |
| Max Boost Clock | Up to 5.7 GHz |
| Base Clock | 4.3 GHz |
| L1 Cache | 1280 KB |
| L2 Cache | 16 Mb |
| L3 Cache | 128 MB |
| Default TDP | 170W |
| Processor Technology for CPU Cores | TSMC 4nm FinFET |
| Processor Technology for I/O Die | TSMC 6nm FinFET |
| Package Die Count | 3 |
| Unlocked for Overclocking | Yes |
| AMD EXPO™ Memory Overclocking Technology | Yes |
| Precision Boost Overdrive | Yes |
| Curve Optimizer Voltage Offsets | Yes |
| AMD Ryzen™ Master Support | Yes |
| CPU Socket | AM5 |
| Supporting Chipsets | A620 , X670E , X670 , B650E , B650 , X870E , X870 , B840 , B850 |
| CPU Boost Technology | Precision Boost 2 |
| Inststuction Set | x86-64 |
| Supported Extensions | AES , AVX512 , AVX2 , AVX , FMA3 , MMX-plus , SSE2 , SSE4.2 , SSE4A , SSE4.1 , SSE3 , SSSE3 , SSE , x86-64 |
| Thermal Solution (PIB) | Not Included |
| Recommended Cooler | Liquid cooler recommended for optimal performance |
| Max. Operating Temperature (Tjmax) | 95°C |
| *OS Support | Windows 11 – 64-Bit Edition , Windows 10 – 64-Bit Edition , RHEL x86 64-Bit , Ubuntu x86 64-Bit |
| Connectivity | |
| Native USB 4 (40Gbps) | 4 |
| Native USB 3.2 Gen 1 (5Gbps) | 1 |
| PCI Express® Version | PCIe® 5.0 |
| Native PCIe® Lanes (Total/Usable) | 28, 24 |
| NVMe Support | Boot , RAID0 , RAID1 , RAID5 , RAID10 |
| System Memory Type | DDR5 |
| Memory Channels | 2 |
| Max. Memory | 192 GB |
| System Memory Subtype | UDIMM |
| Max Memory Speed | 2x1R DDR5-5600 2x2R DDR5-5600 4x1R DDR5-3600 4x2R DDR5-3600 |
| ECC Support | Yes (Requires mobo support) |
| Graphics Capabilities | |
| Graphics Model | AMD Radeon™ Graphics |
| Graphics Core Count | 2 |
| Graphics Frequency | 2200 MHz |
| USB Type-C® DisplayPort™ Alternate Mode | Yes |
| Warranty | 2 Year |
| Note** | **Prices, Specifications & Features are subject to change without notice |
