Description
Features of AMD Ryzen 7 8700G Processor With Radeon Graphics
The AMD Ryzen 7 8700G processor comes with AMD Radeon 780M graphics built in to get you in the game, no graphics card necessary.
AMD Ryzen AI
The dedicated AMD Ryzen AI engine combines the power of the integrated neural processor (NPU), Radeon Graphics, and processor cores to unlock a new level of efficiencies by accelerating AI workloads with compatible applications to deliver faster content generation and enhanced video communications.
Precision Boost 2
Precision Boost Overdrive
Precision Boost Overdrive technology takes advantage of your compatible motherboard’s design to boost clock speeds higher and for longer periods of time. It also allows you to overclock the processor at the touch of a button.
AMD EXPO Technology
The AMD Extended Profiles for Overclocking (AMD EXPO Technology) provides users with advanced profile settings for memory overclocking with supported modules.
AMD Ryzen Master Utility
Personalized Performance
The AMD Ryzen Master Utility provides you with multiple custom profiles to store CPU, GPU, and memory configurations. Use it to configure performance parameters for the active cores and adjust memory times. You can also optimize general performance or fine tune your favorite applications.
System Monitoring
Monitor your system in real-time using the AMD Ryzen Master Utility, which features a histogram of per-core clock rates and temperature, including average and peak readings.
- Feature Ryzen AI™, dedicated Ryzen AI Accelerators to help speed up local AI workloads
- 4nm 65W
- 16MB L3 Cache
- 8MB L2 Cache
- AMD Radeon 780M
Specifications of AMD Ryzen 7 8700G Processor With Radeon Graphics
| Model | AMD Ryzen 7 8700G |
| Product Code | 100-100001236SBX |
| Product Family | AMD Ryzen 8000 Processor |
| Product Line | AMD Ryzen™ 7 8000 G-Series Desktop Processors with Radeon™ Graphics |
| AMD PRO Technologies | No |
| Consumer Use | Yes |
| Regional Availability | Global |
| Former Codename | "Phoenix" |
| Architecture | "Zen 4" |
| # of CPU Cores | 8 |
| Multithreading (SMT) | Yes |
| # of Threads | 16 |
| Max. Boost Clock | Up to 5.1GHz |
| Base Clock | 4.2GHz |
| L2 Cache | 8MB |
| L3 Cache | 16MB |
| Default TDP | 65W |
| AMD Configurable TDP (cTDP) | 45-65W |
| Processor Technology for CPU Cores | TSMC 4nm FinFET |
| CPU Compute Die (CCD) Size | 178mm² |
| Package Die Count | 1 |
| Unlocked for Overclocking | Yes |
| AMD EXPO™ Memory Overclocking Technology | Yes |
| Precision Boost Overdrive | Yes |
| Curve Optimizer Voltage Offsets | Yes |
| AMD Ryzen™ Master Support | Yes |
| CPU Socket | AM5 |
| CPU Boost Technology | Precision Boost 2 |
| Instruction Set | x86-64 |
| Supported Extensions | AES, AMD-V, AVX, AVX2, AVX512, FMA3, MMX(+), SHA, SSE, SSE2, SSE3, SSE4.1, SSE4.2, SSE4A, SSSE3, x86-64 |
| Max. Operating Temperature (Tjmax) | 95°C |
| *OS Support |
Windows 11 - 64-Bit Edition Windows 10 - 64-Bit Edition RHEL x86 64-Bit Ubuntu x86 64-Bit *Operating System (OS) support will vary by manufacturer. |
| Connectivity | |
| Native USB 4 (40Gbps) Ports | 2 |
| Native USB 3.2 Gen 2 (10Gbps) Ports | 2 |
| Native USB 2.0 (480Mbps) Ports | 1 |
| PCI Express® Version | PCIe® 4.0 |
| Native PCIe® Lanes (Total/Usable) | 20 / 16 |
| NVMe Support | Boot, RAID0, RAID1 |
| System Memory Type | DDR5 |
| Memory Channels | 2 |
| Max. Memory | 256GB |
| System Memory Subtype | UDIMM |
| Max Memory Speed |
2x1R DDR5-5200 2x2R DDR5-5200 4X1R DDR5-3600 4x2R DDR5-3600 |
| Graphics Capabilities | |
| Integrated Graphics | Yes |
| Graphics Model | AMD Radeon™ 780M |
| Graphics Core Count | 12 |
| Graphics Frequency | 2900 MHz |
| DirectX® Version | 2.1 |
| DisplayPort Extensions |
HDR Metadata Adaptive-Sync UHBR10 |
| DisplayPort Max Refresh Rates (SDR) |
7680x4320 @ 60Hz 3840x2160 @ 240Hz 3440x1440 @ 360Hz 2560x1440 @ 480Hz 1920x1080 @ 600Hz |
| DisplayPort Max Refresh Rates (HDR) |
7680x4320 @ 60Hz 3840x2160 @ 240Hz 3440x1440 @ 360Hz 2560x1440 @ 480Hz 1920x1080 @ 600Hz |
| HDMI® Version | 2.1 |
| HDCP Version Supported | 2.3 |
| USB Type-C® DisplayPort™ Alternate Mode | Yes |
| Multi-Monitor Support | Yes |
| Max Displays | 4 |
| AMD FreeSync™ | Yes |
| Wireless Display | Miracast |
| Max Video Encode Bandwidth (SDR) |
1080p630 8bpc H.264 1440p373 8bpc H.264 2160p175 8bpc H.264 1080p630 8bpc H.265 1440p373 8bpc H.265 2160p175 8bpc H.265 4320p43 8bpc H.265 1080p864 8/10bpc AV1 1440p513 8/10bpc AV1 2160p240 8/10bpc AV1 4320p60 8/10bpc AV1 |
| Max Video Decode Bandwidth |
1080p60 8bpc MPEG2 1080p60 8bpc VC1 1080p786 8/10bpc VP9 2160p196 8/10bpc VP9 4320p49 8/10bpc VP9 1080p1200 8bpc H.264 2160p300 8bpc H.264 4320p75 8bpc H.264 1080p786 8/10bpc H.265 2160p196 8/10bpc H.265 4320p49 8/10bpc H.265 1080p960 8/10bpc AV1 2160p240 8/10bpc AV1 4320p60 8/10bpc AV1 |
| AMD SmartAccess Memory | Yes |
| AI Engine Capabilities | |
| Brand Name | AMD Ryzen™ AI |
| AMD Ryzen™ AI | Available |
| Performance | Up to 16 TOPS |
| Warranty | 3 Years |
| Note | *** Features, Price, Specifications are subject to change without notice. |
