Feature of SAMSUNG 970 Pro 512GB M.2 NVME Gen3 Solid State Drive ( SSD )
The SAMSUNG 970 Pro 512GB PLUS NVMe M.2 512GB SSD is one of the fastest NVME SSDs on the market. The Samsung 970 EVO PLUS NVMe M.2 512GB SSD delivers sequential write speeds of up to 3500MB / s, driven by an internal Phoenix controller, for the most competitive read and write speeds. higher data accuracy. The Samsung 970 EVO Plus offers efficient and reliable storage that outperforms the previous generation SSDs. Equipped with 3-bit V-NAND technology. This samsung ssd has also updated the SSD firmware and memory manager, giving you total peace of mind. The Samsung 970 EVO Plus outperforms other brands in its niche in speed, capacity, durability, and price.
The Samsung 970 EVO PLUS NVMe M.2 SSD has 512GB of storage and many features that are well worth the price. The sequential read and write speeds are 3500 MB / s and 3300 MB / s, respectively. This flagship M.2 NVMe SSD delivers 4KB at 32 levels of queue depth, reaching 600,000 IOPS and 550,000 IOPS. Deep Queue 1 increases random reads to 19,000 IOPS and random writes to 60,000 IOPS. The Samsung 970 EVO Plus 2TB SSD is a compact M.2 (2280) and can be easily installed on any PCIe Gen 3.0 x4 desktop or laptop. Get your Samsung 970 EVO PLUS NVMe M.2 512GB SSD today for blazing-fast transfer speeds and smoother system responsiveness.
The SSD that goes beyond
Experience the best. For intensive workloads on PCs and workstations, the 970 PRO delivers ultimate performance powered by Samsung's NVMe SSD leadership. The latest V-NAND technology and new Phoenix controller in a compact M.2 (2280) form factor meets the needs of the most demanding tech enthusiasts and professionals.
Fearless Performance
Performance that puts you in command. The 970 PRO combines the next-gen PCIe Gen 3x4 NVMe interface with the latest V-NAND technology and a newly enhanced Phoenix controller to achieve fearless read/write speeds up to 3,500/2,700 MB/s*, approximately 30 percent faster than the previous generation.
Exceptional Endurance
Get the ultimate sustainable performance. The 970 PRO delivers up to 1,200 TBW* with a 5-year limited warranty, achieving 50 percent greater endurance than the previous generation, all powered by the latest V-NAND technology.
Unparalleled Reliability
Achieve a new level of drive confidence. Samsung’s advanced nickel-coated controller and heat spreader on the 970 PRO enable superior heat dissipation. The Dynamic Thermal Guard automatically monitors and maintains optimal operating temperatures to minimize performance drops.
Samsung Magician
Advanced drive management made simple. Samsung Magician software will help you keep an eye on your drive. A suite of user-friendly tools helps keep your drive up to date, monitor drive health and speed, and even boost performance.
Specifications of SAMSUNG 970 Pro 512GB M.2 NVME Gen3 Solid State Drive ( SSD )
| Series | SSD 970 PRO |
| Capacity | 512GB (1GB=1 Billion byte by IDEMA) * Actual usable capacity may be less (due to formatting, partitioning, operating system, applications or otherwise) |
| Usage Application | Client PCs |
| Interface | PCIe Gen 3.0 x4, NVMe 1.3 |
| Sequential Read Speed | Up to 3,500 MB/s * Performance may vary based on system hardware & configuration |
| Sequential Write Speed | Up to 2,300 MB/s * Performance may vary based on system hardware & configuration |
| Random Read Speed | Random Read (4KB, QD32): Up to370,000 IOPS Random Read Random Read (4KB, QD1): Up to15,000 IOPS Random Read *Performance may vary based on system hardware & configuration |
| Random Write Speed | Random Write (4KB, QD32): Up to500,000 IOPS Random Write Random Write (4KB, QD1): Up to55,000 IOPS Random Write * Performance may vary based on system hardware & configuration |
| Controller | Samsung Phoenix Controller |
| NAND Flash | Samsung V-NAND 2-bit MLC |
| Trim Support | Supported |
| AES Encryption | AES 256-bit Encryption (Class 0)TCG/Opal IEEE1667 (Encrypted drive) |
| S.M.A.R.T. Support | Supported |
| GC (Garbage Collection) | Auto Garbage Collection Algorithm |
| Device Sleep Mode Support | Yes |
| Internal Storage | Yes |
| Temperature proof | Yes |
| NVMe | Yes |
| Gaming SSDs | Yes |
| Average Power Consumption (system level) | *Average: 5.2 W *Maximum: 8.5 W (Burst mode) *Actual power consumption may vary depending on system hardware & configuration |
| Power consumption (Idle) | Max. 30 mW *Actual power consumption may vary depending on system hardware & configuration |
| Voltage | 3.3 V ± 5 % Allowable voltage |
| Reliability (MTBF) | 1.5 Million Hours Reliability (MTBF) |
| Operating Temperature | 0 - 70 ℃ Operating Temperature |
| Shock | 1,500 G & 0.5 ms (Half sine) |
| Product | M.2 (2280) |
| Product | 3.16" x 0.09" x 0.87" |
| Product | Max 0.28oz. |
| Management SW | Magician Software for SSD management |
| Warranty | 5 Years |
| Note | ***Features, Price and Specifications are subject to change without notice. |
